I'm Planning a Small Candle Production Unit — How Much Space Should I Allocate Separately for Raw Materials, Melting, Pouring, Curing and Packing?
Share
How do I size the curing zone? Candles per day × production days in your cure period ÷ candles per shelving unit. Measure your own jar and shelf to get the last figure.
Where should melting go? Near a suitable power supply, away from stored fragrance oil and packaging, next to the pour bench to keep trips short.
Should zones be in one line? Ideally yes: materials in, melt, pour, cure, pack, out. Work that doubles back causes collisions and mix-ups.
Size zones from what they hold, not from floor plans
When makers plan a first production unit, they often start with a floor plan and divide it into roughly equal zones. That nearly always leaves too little curing space and too much bench. A better method is to ask one question of each zone: what is the most this area will ever hold at once? Size it for that, add working clearance, and the floor plan follows.
You need four inputs: candles per day, your fill weight, your jar's footprint, and your cure period. Only the first two are decisions you have already made; the other two you measure. Throughout this page the worked example uses 200 candles a day of 200 g each, five days a week, which is 1,000 a week. The jar size, shelf size and cure period in the example are illustrations. Replace them with your own.
Write the results on one sheet and keep it. When output changes later, you rerun the same sums with new inputs rather than starting again, and you can see at once which zone is about to become the constraint.
Zone by zone: what drives the size
| Zone | Sized by | Worked example (replace with yours) |
|---|---|---|
| Raw materials | Weeks of stock held for wax, oil, wicks, jars, packaging | Two weeks: 368 kg wax, 32 kg oil, 2,000 wicks, 2,000 jars |
| Melting | Melter footprint + clearance + electrical supply | One 10 kg melter on a heat-safe stand |
| Pouring | Trays poured per session | Bench long enough for two trays plus scale |
| Curing | Candles/day × production days in cure period | 200 × 10 = 2,000 candles on shelves |
| Packing | Finished goods + box stock + table | One day's packing plus empty boxes |
Raw materials
Wax is denser than people expect and packs compactly. At 1,000 candles a week, wax use is 184 kg, so two weeks of stock is 368 kg, or about 37 cartons of 10 kg. Oil is 16 kg a week and sits on a shelf. Wicks are tiny. Jars are the problem: 2,000 empty jars in their cartons can take more space than all the wax together. Measure a jar carton, count how many jars it holds, and work out the stacked footprint.
Store fragrance oils sealed, upright, cool and away from the melting zone. Wax stored cool and dry keeps well; CSI 464 and CSI 468 each state a shelf life of 60 months in those conditions, so the storage room itself protects your stock.
Melting
The melting zone is small in area but demanding in conditions. It needs a stable, heat-safe surface, clear space all round so nobody brushes hot surfaces, and an electrical supply rated for the melter plus anything else on the same circuit. Keep packaging and fragrance storage out of this zone. Hot wax spills are a burn and fire risk, and cardboard beside a heater is fuel.
Pouring
Size the pour bench for the trays of wicked jars you pour in one session plus a scale and a pitcher rest. Put it beside the melter. A long walk between the two costs more over a day than any extra bench length would.
Curing: the zone that runs out first
Every candle made during your cure period is sitting on a shelf at the same time. That is why curing space scales with both output and cure length.
Eight or nine shelving units is a lot of wall. In many small units it is the largest single area on the plan. Do this calculation before signing for a space, not after the first full week.
Packing and outgoing goods
Packing needs a clear table, flat box stock, filling material and a place for finished cartons to wait for dispatch. Size it for one day's packing plus the box stock you hold. If orders ship in bulk, add space for the outgoing cartons of a single large order, because they tend to arrive at the door all at once.
Think ahead one step when you place this zone. If output doubles, curing grows first and packing second, while melting may not change at all. Put packing and curing next to each other at the open end of the room, so either can expand into spare floor without moving the melter, its wiring or the pour bench.
Keep packing at the far end of the line from melting. Cardboard and paper filler are the most flammable things in the room, and they belong nowhere near hot wax or heating elements.
The small zones people forget
Five headline zones rarely cover everything. Plan for these as well, because each one otherwise ends up squeezed onto a corner of another zone's bench:
None of these is large, but together they can match the pour bench in area. Leaving them out is how a well-sized unit starts feeling cramped within a month.
Arranging zones for one-way flow
Once each zone has an area, arrange them in the order material moves: in through raw materials, then melting, pouring, curing, packing and out. People should never have to carry hot wax back through the curing area, or finished boxes back past the melter.
| Check | Why |
|---|---|
| Melter on a suitable, separate circuit | Avoids overloading sockets and extension leads near hot wax |
| Oil storage away from heat | Some oils have flashpoints below 100°C, such as Roasted Coconut at 93°C |
| Pour bench beside melter | Shortest possible trips with hot pitchers |
| Curing away from melter and sun | Steadier conditions for setting and curing |
| Packing furthest from heat | Cardboard is fuel |
| Clear aisles between zones | Room to pass with a full pitcher safely |
The honest answer: most first units are rented with the melter in mind and outgrown by the shelves. Run the curing calculation with your own numbers, then look at spaces. A room that fits your shelving comfortably will almost always fit the rest of the operation too.
Where this page fits
CSI already has guides that cover parts of this question. This page takes the production-floor angle; these go deeper on the rest:
Three things to buy for this job
| Option | Price | Status on the September 2026 pull |
|---|---|---|
| 10 kg capacity | ₹21,240.00 | In stock |
| 20 kg capacity | ₹25,960.00 | In stock |
| Option | Price | Status on the September 2026 pull |
|---|---|---|
| 500 g | ₹260.00 | In stock |
| 1 kg | ₹507.40 | In stock |
| 5 kg | ₹2,537.00 | In stock |
| 10 kg | ₹5,074.00 | In stock |
| Option | Price | Status on the September 2026 pull |
|---|---|---|
| Large 600 ml | ₹708.00 | In stock |
| Small 150 ml | ₹354.00 | Out of stock |
